Customized JL667A 6300F Network Ethernet Switch with 48x 10/100/1000BaseT Ports and 4x 1/10/25/50G SFP Ports LACP Function

Name: Customized JL667A 6300F Network Ethernet Switch with 48x 10/100/1000BaseT Ports and 4x 1/10/25/50G SFP Ports LACP Function
Brand: Beijing Hui Tong High Tech Limited.
SKU: JL667A
Price: 1,928.00 USD
Availability: InStock

Model Number:	JL667A
MOQ:	2
Price:	$1868-$1988
Payment Terms:	T/T,D/P,D/A

Detail Information

Product Description

Detail Information

Place of Origin:

China

Private Mold:

Products Status:

Stock

Ports:

≥ 48

Transmission Rate:

10/100/1000Mbps

Function:

LACP, POE, QoS, SNMP

Communication Mode:

Full-Duplex & Half-Duplex

Switch Capacity:

Brand Name:

Model Number:

JL667A

Place Of Origin:

Shanghai, China

Product Model:

CX 6300F JL667A

Product Type:

Enterprise-class Switch

Application Level:

Layer 2

PoE Power Supply:

PoE Function Is Not Supported

Power Supply:

Internal (fixed) Power Supply, 200W

Highlight:

48-port Gigabit Ethernet switch LACP

25G SFP network switch with LACP

customized 6300F series networking switch

Product Description

Customized JL667A 6300F Serials Network Ethernet Switch LACP Function 48x 10/100/1000BaseT Ports and 4x 1/10/25/50G SFP Ports

The Aruba 6300F JL667A is a modern, high-performance switch with 48 ports of 1GbE and 4 SFP56 ports. Perfect for medium to large enterprises, the JL667A delivers superb functionality, speed, and reliability.

Product Features

High-performance switch with 48 1GbE ports and 4 SFP56 ports
Part of the reliable Aruba 6300F series
Supports Aruba's advanced security and network management tools
Designed for efficient operation and energy savings

Product Applications

Ideal for medium to large enterprise networks
Great for high-speed data transfers and link aggregation
Suitable for connecting various network devices, including servers, storage, and wireless APs

JL667A Specifications

Description	48x ports 10/100/1000BaseT Ports 4x 1G/10G/25G/50G SFP ports 1x USB C Console Port 1x OOBM port 1x USB Type A Host port
Power supplies	Internal (fixed) power supply (200W)
Fans	Fixed fans
Dimensions	(H) 4.39 cm x (W) 44.2 cm x (D) 32.7 cm (1.73" x 17.4" x 12.9")
Configuration weight	4.46 kg (9.83 lb)
CPU	Quad Core Arm Cortex A72 @ 1.8GHz
Memory and flash	8 GB DDR4 32 GB eMMC
Packet buffer	8 MB
Switching capacity	496 Gbps
Throughput capacity	369 Mpps
Operating temperature	32°F to 113°F (0°C to 45°C) up to 5,000 ft. Derate 1 degree C for every 1,000 ft from 5,000 ft to 10,000 ft. Can support excursion to 131°F (55°C) for short periods of time.
Operating relative humidity	5% to 95% @ 104°F (40°C) non condensing
Frequency	50Hz/60Hz
AC voltage	Fixed PSU: 100V-120V/200V-240V
Current (for voltages listed above)	Fixed PSU: 2.5A/1.4A
