Customized CX6000 Series 24 Port Gigabit Network Ethernet Switch with 10/100/1000Mbps and PoE+ Support

Customized CX6000 Series 24 Port Gigabit Network Ethernet Switch with 10/100/1000Mbps and PoE+ Support

Customized CX6000 Series 24 Port Gigabit Network Ethernet Switch with 10/100/1000Mbps and PoE+ Support

Model Number: R8N87A
MOQ: 2
Price: $688-$718
Payment Terms: T/T,D/P,D/A
Detail Information
Product Description
Detail Information
Place of Origin:
China
Private Mold:
NO
Products Status:
Stock
Ports:
≥ 48
Transmission Rate:
10/100/1000Mbps
Function:
LACP, POE, QoS, SNMP
Communication Mode:
Full-Duplex & Half-Duplex
Switch Capacity:
/
Brand Name:
/
Model Number:
R8N87A
Place Of Origin:
Shanghai, China
Size:
Customized Size
Color:
Customizable
Suitable For:
Workstation, Laptop, Desktop
Highlight:

24 port gigabit network switch

,

CX6000 series ethernet switch

,

CL4 4SFP networking switch

Product Description
CX6000 Series 24 Port Gigabit Network Switch
Product Code: R8N87A
Customized 24-port CL4 4SFP Gigabit Ethernet Switch with 10/100/1000Mbps Transmission Rate
Key Specifications
Port Configuration 24 x 10/100/1000 Base-T RJ-45 PoE+ ports
4 x Gigabit SFP ports
Power Over Ethernet PoE+ with 370W total budget
Switching Capacity 56 Gbps
Throughput 41.6 Mpps
Latency 1.5 µs (1 Gbps)
Technical Details
Management
Managed, Stackable
Enclosure
1U Rack-mountable
MAC Address Table
8,192 entries
Jumbo Frames
9,198 bytes
Performance & Capacity
Packet Buffer Size 12.38 MB
Switched Virtual Interfaces 16
ARP Entries 1,024
IPv4/IPv6 Routes 512 each
IGMP/MLD Groups 512 each
Connectivity & Interfaces
  • 24 x 10/100/1000 Base-T RJ-45 PoE Class 4 ports (370W total)
  • 4 x Gigabit LAN SFP ports
  • 1 x USB Type A port
  • 1 x USB-C console port
Power Specifications
Power Supply Internal
Input Voltage AC 100-240 V (50/60 Hz)
Operational Power Consumption 32.7 Watt
PoE Budget 370 W
Management & Security
  • Remote Management: SNMP 1/2c/3, HTTP, HTTPS, RADIUS
  • Authentication: SSH, RADIUS, TACACS+, SSH2
  • Encryption: SSL
  • Routing Protocol: IGMPv2, IGMPv3
Advanced Features
  • VLAN support and Multiple Spanning Tree Protocol (MSTP)
  • Access Control List (ACL) support
  • IPv6 support with Neighbor Discovery Protocol
  • Flow control and Quality of Service (DiffServ)
  • LLDP and LLDP-MED support
  • Trusted Platform Module (TPM) security
  • Fanless operation
Physical Dimensions
Width 17.4 inches
Depth 10.6 inches
Height 1.7 inches (1U)
Environmental Specifications
Operating Temperature 32°F to 113°F (0°C to 45°C)
Operating Humidity 15% to 95% (non-condensing)
Storage Humidity 15% to 90% (non-condensing)
Warranty & Compliance
Warranty Limited lifetime warranty
Standards Compliance IEEE 802.3 series, UL, IEC, FCC, CE, and other international standards
