EX2300-24T-DC 24 Port 10/100/1000Mbps Gigabit Ethernet Network Switch with Full-Duplex Half-Duplex Communication Mode

Name: EX2300-24T-DC 24 Port 10/100/1000Mbps Gigabit Ethernet Network Switch with Full-Duplex Half-Duplex Communication Mode
Brand: Beijing Hui Tong High Tech Limited.
SKU: EX2300-24T-DC
Price: 871.00 USD
Availability: InStock

Model Number:	EX2300-24T-DC
MOQ:	2
Price:	$856-$886
Payment Terms:	T/T,D/P,D/A

Detail Information

Product Description

Detail Information

Place of Origin:

China

Private Mold:

Products Status:

Stock

Ports:

Transmission Rate:

10/100/1000Mbps

Function:

LACP, POE, QoS, SNMP

Communication Mode:

Full-Duplex & Half-Duplex

Switch Capacity:

Brand Name:

Model Number:

EX2300-24T

Place Of Origin:

Shanghai, China

Size:

Customized Size

Color:

Customizable

Suitable For:

Workstation, Laptop, Desktop

Highlight:

24 port gigabit ethernet switch

10/100/1000 network switch

full-duplex half-duplex networking switch

Product Description

EX2300-24T-DC 24 Port Gigabit Ethernet Switch

High-performance 24-port 10/100/1000BASE-T network switch with full-duplex and half-duplex communication modes, designed for reliable industrial networking applications.

Key Features:

24 x 10/100/1000BASE-T copper ports
4 x 1/10GbE SFP/SFP+ uplink ports (optics sold separately)
80 Gbps backplane speed with 128 Gbps data rate
95 Mpps wire speed throughput
Integrated power supply and fan for maximum resiliency

Technical Specifications

Port Configuration	24-port 10/100/1000BASE-T, 4 x 1/10GbE SFP/SFP+
Dimensions (W x H x D)	17.4 x 1.75 x 10.2 in (44.19 x 4.45 x 25.9 cm) 1 rack unit
Backplane Speed	80 Gbps
Data Rate	128 Gbps
Throughput	95 Mpps (wire speed)
Quality of Service (QoS)	8 queues per port
MAC Address Table	16,000 entries
Jumbo Frames	9216 bytes
IPv4 Routes	4096 unicast / 2048 multicast
IPv6 Routes	2048 unicast / 1024 multicast
VLAN Support	4093 VLANs
ARP Entries	1500
Traffic Monitoring	sFlow
Resiliency	Integrated power supply and fans
