QFX5120-48Y Layer 3 Managed Switch with 48 x 1/10/25 Gigabit Ports and 2 Tbps Switching Capacity for Data Centers

Name: QFX5120-48Y Layer 3 Managed Switch with 48 x 1/10/25 Gigabit Ports and 2 Tbps Switching Capacity for Data Centers
Brand: Beijing Hui Tong High Tech Limited.
SKU: QFX5120-48Y-AFI2
Price: 5,753.00 USD
Availability: InStock

Model Number:	QFX5120-48Y-AFI2
MOQ:	2
Price:	$5638-$5868
Payment Terms:	T/T,D/P,D/A

Detail Information

Product Description

Detail Information

Place of Origin:

China

Private Mold:

Products Status:

Stock

Ports:

≥ 48

Transmission Rate:

10/100/1000Mbps

Function:

LACP, POE, QoS, SNMP

Communication Mode:

Full-Duplex & Half-Duplex

Switch Capacity:

Brand Name:

Model Number:

QFX5120-48Y

Place Of Origin:

Shanghai, China

Size:

Customized Size

Color:

Customizable

Suitable For:

Workstation, Laptop, Desktop

Highlight:

QFX5120-48Y-AFI2 Layer 3 managed switch

48-port Gigabit Ethernet switch

enterprise data center networking switch

Product Description

QFX5120-48Y-AFI2 Layer 3 Managed Switch

High-performance 48-port switch designed for large enterprises and data centers, delivering exceptional routing and switching capabilities with 1/10/25 Gigabit connectivity.

Product Overview

The Juniper Networks QFX5120 Switch provides high scale, availability, and performance for data center and campus deployments. This versatile platform addresses higher server access speed requirements and campus distribution use cases while offering high-density connectivity options.

Key Features

48 x 1/10/25GbE SFP28 downlink ports with 8 x 40/100GbE QSFP28 uplink ports
Up to 2/4 Tbps Layer 2 and Layer 3 performance with ultra-low latency (800 nanoseconds)
2.2 GHz quad-core Intel CPU with 16 GB memory and 50 GB SSD storage
Flexible port configuration using breakout cables for expanded connectivity
Comprehensive routing protocols including OSPF, BGP, MPLS, and static routing
Advanced management features including Zero-touch provisioning (ZTP) and Junos XML

Port Configuration Flexibility: Each of the eight 100GbE QSFP28 ports can be broken into four 25GbE SFP28 ports, while 40GbE QSFP+ ports can be broken into four 10GbE SFP+ ports, supporting up to 80 total 25GbE/10GbE ports.

Technical Specifications

Model	QFX5120-48Y-AFI2
Device Type	Switch - 48 ports - L3 - managed - stackable
Enclosure	Back to front airflow rack-mountable 1U
Ports	48 x 1/10/25 Gigabit SFP28 + 8 x 40/100 Gigabit QSFP28
Performance	Switching capacity: 2 Tbps ¦ Switching capacity: 1.31 Bpps
MAC Address Table	288K entries
Jumbo Frame Support	9216 bytes
Processor	1 x Intel: 2.2 GHz
Memory	16 GB RAM, 64 GB Flash Memory
Interfaces	48 x 1/10/25Gbit LAN SFP28 ¦ 8 x 100Gbit/40Gbit LAN QSFP28 ¦ 1 x USB 2.0 ¦ 1 x management (RS-232) ¦ 2 x management RJ-45
Power Supply	2 x 650W hot-plug internal power supplies with 1+1 redundancy
Power Consumption	260 Watt (operational)

Advanced Capabilities

Supports comprehensive networking protocols including OSPF, BGP, MPLS, VXLAN, EVPN, and multichassis link aggregation (MC-LAG). Features advanced QoS, sFlow v5, Priority-Based Flow Control (PFC), and extensive VLAN support with 4093 virtual interfaces.

Compliance & Standards

Compliant with IEEE 802.1D, 802.1Q, 802.3ad (LACP), 802.1w, 802.1s, and other industry standards for reliable enterprise and data center operation.
