S6730-H28Y4C Managed Core Switch with 28 25GE and 4 100GE Ports for High-Speed Networking

Name: S6730-H28Y4C Managed Core Switch with 28 25GE and 4 100GE Ports for High-Speed Networking
Brand: Beijing Hui Tong High Tech Limited.
SKU: S6730-H28Y4C
Price: 2,870.00 USD
Availability: InStock

Model Number:	S6730-H28Y4C
MOQ:	1
Price:	$2760-$2980
Payment Terms:	T/T,D/P,D/A

Detail Information

Product Description

Detail Information

Place of Origin:

China

Private Mold:

Products Status:

Stock

Ports:

Transmission Rate:

10/100/1000Mbps

Function:

LACP, POE, QoS, SNMP

Communication Mode:

Full-Duplex & Half-Duplex

Switch Capacity:

Brand Name:

Model Number:

S6730-H28Y4C

Place Of Origin:

Shanghai, China

Size:

Customized Size

Color:

Customizable

Suitable For:

Workstation, Laptop, Desktop

Highlight:

managed core switch with 25GE ports

private mold switch with 100GE ports

networking switch with 28 25GE ports

Product Description

S6730-H28Y4C Managed Core Switch

High-performance managed core switch with 28×25GE SFP28 ports and 4×100GE QSFP28 ports, designed for enterprise and data center networking applications.

Product Overview

Description	S6730-H28Y4C (28×25GE SFP28 ports, 4×100GE QSFP28 ports, without power module)
Part Number	02353LGV-003
Model	S6730-H28Y4C
First Supported Version	V200R021C10SPC600
Supported Patch Version	If the device is used in V200R021C00SPC100, install V200R021SPH013 or later patch

Technical Specifications

Dimensions without packaging (H × W × D)	Basic dimensions: 43.6 mm × 442.0 mm × 220.0 mm (1.72 in. × 17.4 in. × 8.66 in.) Maximum dimensions: 43.6 mm × 442.0 mm × 231.0 mm (1.72 in. × 17.40 in. × 9.09 in.)
Dimensions with packaging (H × W × D)	115 mm × 545 mm × 360 mm (4.53 in. × 21.46 in. × 14.17 in.)
Weight without packaging	3.4 kg (7.5 lb)
Weight with packaging	4.65 kg (10.25 lb)
Typical power consumption	186 W
Typical heat dissipation	634.65 BTU/hour
Maximum power consumption	253 W
Maximum heat dissipation	863.26 BTU/hour
Static power consumption	116 W
MTBF	54.68 years
MTTR	2 hours
Availability	>0.99999
Noise at normal temperature (acoustic power)	64.5 dB(A)
Noise at normal temperature (acoustic pressure)	51.7 dB(A)
Number of power slots	2
Number of fan modules	3
Long-term operating temperature	-5°C to +45°C (23°F to 113°F) at 0-1800 m (0-5905.44 ft.) altitude
Storage temperature	-40°C to +70°C (-40°F to +158°F)
Long-term operating relative humidity	5% RH to 95% RH (non-condensing)
Long-term operating altitude	0-5000 m (0-16404 ft.)
Storage altitude	0-5000 m (0-16404 ft.)
Power supply mode	Pluggable power supply
Rated input voltage	AC input: 100-240 V AC; 50/60 Hz High-voltage DC input: 240 V DC DC input: -48 V DC to -60 V DC
Input voltage range	AC input: 90-290 V AC; 45-65 Hz High-voltage DC input: 190-290 V DC DC input: -38.4 V DC to -72 V DC
Memory	4 GB
Flash memory	2 GB total (view available size using display version command)
Console port	RJ45
Eth Management port	RJ45
USB	Supported
RTC	Supported
Power supply surge protection	AC power module: ±6 kV differential mode, ±6 kV common mode DC power module: ±2 kV differential mode, ±4 kV common mode
Types of fans	Built-in
Certification	EMC certification, Safety certification, Manufacturing certification

Product Model	CloudEngine S6730-H48X6C	CloudEngine S6730-H24X6C	CloudEngine S6730-H24X4Y4C
Switching Capacity	2.16/2.4 Tbit/s	1.68/2.4 Tbit/s	1.48Tbps/2.4Tbps
Fixed Ports	48 × 10 GE SFP+ 6 × 40/100 GE QSFP28	24 × 10 GE SFP+ 6 × 40/100 GE downlink QSFP28	24 × 10 Gig SFP+ 4 × 25 Gig SFP28 4 × 100 Gig QSFP28
