| MOQ: | 2 pieces |
| Price: | CN¥1,970.91/pieces >=2 pieces |
Software | Catalyst 9105 AXI ● Cisco Unified Wireless Network Software Release 8.10.MR3 or later ● Cisco IOS ® XE Software Release 17.3.1, or later | |||
Supported wireless LAN controllers | ● Cisco Catalyst 9800 Series Wireless Controllers ● Cisco 3504, 5520, and 8540 Wireless Controllers and Cisco Virtual Wireless Controller | |||
802.11n version 2.0 (and related) capabilities | ● 2x2 MIMO with two spatial streams ● Maximal Ratio Combining (MRC) ● 802.11n and 802.11a/g ● 20- and 40-MHz channels ● PHY data rates up to 444.4 Mbps (40 MHz with 5 GHz and 20 MHz with 2.4 GHz) ● Packet aggregation: Aggregate MAC Protocol Data Unit (A-MPDU) (transmit and receive), Aggregate MAC Service Data Unit (A-MSDU) (transmit and receive) ● 802.11 Dynamic Frequency Selection (DFS) ● Cyclic Shift Diversity (CSD) support | |||
802.11ac | ● 2x2 downlink MU-MIMO with two spatial streams ● MRC ● 802.11ac beamforming ● 20-, 40-, 80- MHz channels ● PHY data rates up to 866.7 Mbps (80 MHz with 5GHz) ● Packet aggregation: A-MPDU (transmit and receive), A-MSDU (transmit and receive) ● 802.11 DFS ● CSD support ● WPA3 support | |||
802.11ax | ● 2x2 uplink/downlink MU-MIMO with two spatial streams ● Uplink/downlink OFDMA ● TWT ● BSS coloring ● MRC ● 802.11ax beamforming ● 20-, 40-, 80- channels ● PHY data rates up to 1.488 Gbps (80 MHz with 5 GHz and 20 MHz with 2.4 GHz) ● Packet aggregation: A-MPDU (transmit and receive), A-MSDU (transmit and receive) ● 802.11 DFS ● CSD support ● WPA3 support | |||
Integrated antenna | Catalyst 9105AXI ● 2.4 GHz: Peak gain 4 dBi, internal antenna, omnidirectional in azimuth ● 5 GHz: Peak gain 5 dBi, internal antenna, omnidirectional in azimuth | |||
Dimensions (W x L x H) | Access point (without mounting brackets): C9105AXI: 5.9 x 5.9 x 1.18 in. (150 x 150 x 30 mm) | |||
item | value | |||
Products Status | Stock | |||
Place of Origin | China | |||
AirEngine 6761-21E: External antennas | ||||
MIMO:Spatial Streams | 2.4 GHz: 4 x 4:4, 5 GHz: 4 x 4:4 | |||
Radio Protocols | 802.11a/b/g/n/ac/ac wave2/ax | |||
Maximum Rate | 3.55 Gbit/s | |||
