Type	Oem Supported Server Storage Ram Nas Rack Internet Server 2288Hv7 2288Hv6
Form Factor	2U Rack Server
Processor	1 or 2 1st Generation Intel® Xeon® Scalable processors (3100/4100/5100/6100/8100 series), up to 205W 1 or 2 2nd Generation Intel® Xeon® Scalable processors (3200/4200/5200/6200/8200 series), up to 205W
PCIe Expansion	Up to 10 PCIe 3.0 slots, including 1 for a RAID controller card and 1 for a flexible NIC
Memory	24 DDR4 DIMM slots, 2933 MT/s; up to 12 Intel® Optane™ PMem modules (100 series), 2666 MT/s
Network Ports	LOM: 2 x 10 GE + 2 x GE ports Flexible NIC: 2 x GE, 4 x GE, 2 x 10 GE, 2 x 25 GE, or 1/2 x 56G FDR IB ports
Internal Storage	Supports hot-pluggable drives with the following configuration options: 8 x 2.5-inch SAS/SATA HDDs or SSDs 12/16/20 x 3.5-inch SAS/SATA HDDs 4, 8, 12, 24, or 28 NVMe SSDs 31 x 2.5-inch SAS/SATA HDDs or SSDs Flash storage: 2 M.2 SSDs
RAID Support	RAID 0, 1, 10, 1E, 5, 50, 6, or 60 Configured with a supercapacitor for cache power-off protection (optional) RAID level migration, drive roaming, self-diagnosis, and web-based remote configuration
Heterogeneous Accelerator Card	Up to 7 single-width half-height half-length accelerator cards Up to 2 dual-width full-height full-length accelerator cards
Dimensions (H x W x D)	Chassis with 3.5-inch hard drives: 86.1 mm x 447 mm x 748 mm (3.39 in. x 17.60 in. x 29.45 in.) Chassis with 2.5-inch hard drives: 86.1 mm x 447 mm x 708 mm (3.39 in. x 17.60 in. x 27.87 in.)
OEM-ready version available	From bezel to BIOS to packaging, your servers can look and feel as if they were designed and built by you.

Tel	+86 18664937360
Skype	+86 18664937360
WhatsApp/Wechat	+86 18664937360
Email	amy-ai at asia-hitech.com
Website	www.asia-hitech.com

Brand Name:	\
Model Number:	2288HV7
MOQ:	2
Price:	$1,650-1,850
