S5735-L Enterprise Switch with 48GE SFP Ports 410GE SFP+ Ports and PoE+ for High-Speed Networking

Model Number:	S5735-L48S4X-A-V2
MOQ:	2
Price:	CN¥4,728.56-5,003.48

Detail Information

Product Description

Detail Information

Place of Origin:

Beijing, China

Communication Mode:

Full-Duplex & Half-Duplex

Transmission Rate:

10/100/1000Mbps

Function:

LACP, POE, QoS, Stackable, VLAN Support

Ports:

≥ 48

Private Mold:

Products Status:

Stock

Highlight:

48-port PoE+ network switch

Enterprise switch with SFP ports

10GE SFP+ network switch

Product Description

Description	S5735-L48S4X-A-V2 (48GE SFP ports, 410GE SFP+ ports, built-in AC power, front access)
Part Number	98012273
Model	S5735-L48S4X-A-V2
First supported version	V600R023C00
Remarks	Copper modules can be installed on a maximum of 24 1000BASE-X optical ports.
Technical Specifications
Dimensions without packaging (H x W x D) [mm(in.)]	Basic dimensions (excluding the parts protruding from the body): 43.6 mm x 442.0 mm x 220.0 mm (1.72 in. x 17.4 in. x 8.66 in.) Maximum dimensions (the depth is the distance from ports on the front panel to the parts protruding from the rear panel): 43.6 mm x 442.0 mm x 227.0 mm (1.72 in. x 17.4 in. x 8.94 in.)
Dimensions with packaging (H x W x D) [mm(in.)]	90.0 mm x 550.0 mm x 360.0 mm (3.54 in. x 21.65 in. x 14.17 in.)
Chassis height [U]	1
Chassis material	Metal
Weight without packaging [kg(lb)]	3.28 kg (7.23 lb)
Weight with packaging [kg(lb)]	3.89 kg (8.58 lb)
Typical power consumption [W]	65.6
Typical heat dissipation [BTU/hour]	223.83
Maximum power consumption [W]	84.1
Maximum heat dissipation [BTU/hour]	286.96
Static power consumption	32
MTBF [years]	47.14
MTTR [hours]	2
Availability	> 0.99999
Noise at normal temperature (acoustic power) [dB(A)]	45.6
Noise at normal temperature (acoustic pressure) [dB(A)]	33.6
Number of card slots	0
Number of power slots	0
Number of fans modules	2
Long-term operating temperature [°C(°F)]	-5°C to +50°C (23°F to 122°F) at an altitude of 0-1800 m (0-5905.44 ft.)
Restriction on the operating temperature variation rate [°C(°F)]	When the altitude is 1800–5000 m (5906–16404 ft.), the highest operating temperature reduces by 1°C (1.8°F) every time the altitude increases by 220 m (722 ft.). Devices cannot start when the temperature is lower than 0°C (32°F).
Storage temperature [°C(°F)]	–40°C to +70°C (–40°F to +158°F)
Long-term operating relative humidity [RH]	5% RH to 95% RH (non-condensing)
Long-term operating altitude [m(ft.)]	0–5000 m (0–16404 ft.)
Storage altitude [m(ft.)]	0-5000 m (0-16404 ft.)
Power supply mode	AC built-in
Maximum input current [A]	3 A
Memory	2 GB
Flash memory	Physical space: 1 GB
Console port	RJ45
