C1200 Series 24-Port Managed Ethernet Switch with PoE+ Support and Layer 2 with Layer 3 Static Routing

C1200 Series 24-Port Managed Ethernet Switch with PoE+ Support and Layer 2 with Layer 3 Static Routing

Brand Name: Cisco
Model Number: C1200-24FP-4X
MOQ: 2
Price: $1,012-1,072
Detail Information
Place of Origin:
Beijing, China
Communication Mode:
Full-Duplex & Half-Duplex
Transmission Rate:
10/100/1000Mbps
Function:
LACP, POE, QoS, Stackable, VLAN Support
Ports:
24
Private Mold:
No
Products Status:
Stock
Highlight:

24-port PoE+ managed Ethernet switch

,

C1200 Series Gigabit uplink switch

,

24-port networking switch with PoE+

Product Description

Product Description

The C1200 Series is the next generation of affordable smart switches, combining powerful performance and reliability with a complete suite of the features you need for a small or medium-sized business network. The switches operate on customized Linux OS software and provide flexible management options, comprehensive security capabilities, and Layer 3 static routing features far beyond those of an unmanaged or consumer-grade switch, at a lower cost than for fully managed switches. When you need a reliable solution to share online resources and connect computers, phones, and wireless access points, the C1200 Series smart switches provide the ideal solution at an affordable pricing point.

Cisco C1200-24FP-4X Specification

Specification
Details
Model
Cisco Catalyst C1200-24FP-4X
Description
24-Port Managed Ethernet Switch with PoE+ and 4 Gigabit Ethernet Uplinks
Product Type
Managed Layer 2 Ethernet Switch with Power over Ethernet (PoE+)
Form Factor
Rackmount, 1U
Ports
24 x 10/100/1000 Ethernet Ports with PoE+
Uplink Ports
4 x 10/100/1000 Gigabit Ethernet Uplinks
Power over Ethernet (PoE)
Yes (PoE+ support, up to 30W per port)
Total PoE Budget
370W (Maximum PoE+ power budget)
Switching Capacity
56 Gbps
Stacking Bandwidth
N/A (No stacking support)
Forwarding Rate
41.6 Million Packets per Second (Mpps)
Layer
Layer 2 (With limited Layer 3 static routing capabilities)
DRAM
256 MB
Flash
128 MB
MAC Address Table
16,000 MAC addresses
VLAN Support
IEEE 802.1Q VLAN Support, up to 4096 VLANs
Jumbo Frame Support
Yes (Up to 9216 bytes)
Stacking
Not supported
Port Mirroring
Yes (Supports port mirroring for network monitoring)
Redundancy Features
Dual Redundant Power Supply (Optional)
Power Supply
Internal, 100-240V, 50/60 Hz, AC Input
Hardware Forwarding
Yes (Hardware-based forwarding for high performance)
3 Protocolsaver
Supports Spanning Tree Protocol (STP), Rapid Spanning Tree Protocol (RSTP), and Multiple Spanning Tree Protocol (MSTP)
Layer 3 Protocols Supported
Static Routing, RIP v1/v2
Quality of Service (QoS)
Layer 2/Layer 3 QoS Support (802.1p, DiffServ, and priority queuing)
IPv6 Support
Yes (Basic IPv6 support for management and routing)
PoE+ Features
Yes (Provides up to 30W per port for PoE+ powered devices)
Dimensions (H x W x D)
1.75 x 17.5 x 10.5 inches (44.5 x 444 x 267 mm)
Weight
5.5 lbs (2.5 kg)
