New Original AR6140E-9G-2AC NetEngine AR6100 AC Host 5GE RJ45 4GE SFP, 1USB 3.0 4SIC Enterprise Routers

Price:	CN¥422.74/pieces >=1 pieces

Detail Information

Product Description

Detail Information

Max. Lan Data Rate:

1000Mbps

With Modem Function:

Yes

Standards And Protocols:

Wi-Fi 802.11g

Wi-fi Supported Frequency:

2.4GHz & 5.2GHz & 5.8GHz

Supports WDS:

Supports WPS:

Wi-fi Transmission Standard:

802.11b

Wired Transfer Rate:

None

2.4g Wi-fi Transmission Rate:

600Mbps

Encryption Type:

WPA2-PSK

Private Mold:

Products Status:

New

Type:

Wireless

Application:

Network Security

Function:

QoS

Lan Ports:

Antennas:

2 External Antennas

WAN Ports:

1 X10/100/1000Mbps

Brand:

Place Of Origin:

Beijing, China

5g Wi-fi Transmission Rate:

1000Mbps

Highlight:

1*USB 3.0 Enterprise Routers

4*GE SFP Enterprise Routers

5*GE RJ45 Enterprise Routers

Product Description

AR6140E-9G-2AC

Item	Specification
Installation type	Rack
Chassis height [U]	1 U
Dimensions without packaging (H x W x D) [mm(in.)]	Basic dimensions (excluding the parts protruding from the body): 44.4 mm x 442.0 mm x 428.2 mm (1.75 in. x 17.4 in. x 16.86 in.) Maximum dimensions (the depth is the distance from ports on the front panel to the handle on the rear panel): 44.4 mm x 442.0 mm x 431.2 mm (1.75 in. x 17.4 in. x 16.98 in.)
Dimensions with packaging (H x W x D) [mm(in.)]	175 mm x 550 mm x 710 mm (6.89 in. x 21.65 in. x 27.95 in.)
Weight with packaging [kg(lb)]	7.75 kg (17.09 lb)
Weight without packaging [kg(lb)]	5.35 kg (11.79 lb)
CPU	1.4 GHz, 4 Cores
Memory	4 GB
NAND Flash	1 GB
Console port	RJ45
RTC	Supported
LAN ports	2 x GE SFP, 3 x GE electrical
WAN ports	2 x GE SFP, 2 x GE electrical
Number of service board slots	4
MIC slots (default/maximum)	0/0
SIC slots (default/maximum)	4/4
WSIC slots (default/maximum)	0/2
XSIC slots (default/maximum)	0/0
Redundant MPUs	Not supported
RPS input	Not supported
PoE	Not supported
IP rating	IP20
MTBF [years]	64.50 years
MTTR [hours]	2 hours
Availability	0.9999964601
Typical power consumption [W]	22 W
Maximum power consumption [W]	28 W
Power supply mode	AC built-in
Number of power modules	2
Rated input voltage [V]	100 V to 240 V, 50 Hz/60 Hz
Input voltage range [V]	90 V to 264 V, 47 Hz to 63 Hz
Maximum input current [A]	2 A
Maximum output power [W]	70 W
Redundant power supply	Dual power supplies in 1:1 backup mode
Types of fans	Built-in
Number of fan modules	2
Heat dissipation mode	Air cooling
Airflow	Left-to-right airflow
Noise at normal temperature (acoustic power) [dB(A)]	49.9 dB(A)
