QFX5120-48YM-AFI Network Switch with 48X25G and 8X100G Ports Supporting 10/100/1000Mbps Ethernet

Name: QFX5120-48YM-AFI Network Switch with 48X25G and 8X100G Ports Supporting 10/100/1000Mbps Ethernet
Brand: Beijing Hui Tong High Tech Limited.
SKU: QFX5120-48YM-AFI
Price: 6,632.00 USD
Availability: InStock

Model Number:	QFX5120-48YM-AFI
MOQ:	1
Price:	$6352-$6912
Payment Terms:	T/T,D/P,D/A

Detail Information

Product Description

Detail Information

Place of Origin:

China

Private Mold:

Products Status:

Stock

Ports:

Transmission Rate:

10/100/1000Mbps

Function:

LACP, POE, QoS, SNMP

Communication Mode:

Full-Duplex & Half-Duplex

Switch Capacity:

Brand Name:

Model Number:

QFX5120-48YM-AFI

Place Of Origin:

Shanghai, China

Size:

Customized Size

Color:

Customizable

Suitable For:

Workstation, Laptop, Desktop

Highlight:

QFX5120-48YM network switch 48x25G

QFX5120 series switch with AES256 encryption

full-duplex half-duplex networking switch 10/100/1000Mbps

Product Description

QFX5120-48YM-AFI Network Switch

High-performance 48-port 25GbE network switch with 8x100G uplinks, supporting full-duplex and half-duplex operation with 10/100/1000Mbps connectivity and AES256 encryption.

Product Overview

The QFX5120-48YM-AFI is a premium network switch featuring 48 downlink 25GbE ports with Power over Ethernet (PoE) support and Quality of Service (QoS) capabilities. This Gigabit Ethernet switch delivers exceptional performance for demanding enterprise and data center environments.

Model Comparison

Specification	QFX5120-48Y	QFX5120-48YM	QFX5120-48T	QFX5120-32C
Dimensions (H x W x D)	1.72 x 17.36 x 20.48 in. (4.37 x 44.09 x 52.02 cm)	1.72 x 17.36 x 20.48 in. (4.37 x 44.09 x 52.02 cm)	1.72 x 17.36 x 20.48 in. (4.37 x 44.09 x 52.02 cm)	1.7 x 17.26 x 20.27 in. (4.32 x 43.84 x 51.5 cm)
Weight	23.7 lb (10.75 kg)	24.8 lb (11.25 kg)	24.25 lb (11 kg)	21.12 lb (9.58 kg)
Switching Capacity	4 Tbps (bidirectional) 1.31 Bpps	4 Tbps (bidirectional) 1.31 Bpps	2.16 Tbps (bidirectional) 1001.7 Mpps	6.4 Tbps (bidirectional) 2 Bpps
Switching Mode	Cut-through and store-and-forward	Cut-through and store-and-forward	Cut-through and store-and-forward	Cut-through and store-and-forward
Power Consumption	Max: 450 W Typical: 260 W	Max: 650 W Typical: 550 W	Max: 450 W Typical: 300 W	Max: 515 W Typical: 380 W

Interface Options

QFX5120-48YM-AFI Specific Interfaces

2 management ports: 2 x RJ-45 ports
1GbE SFP: 48 ports
10GbE SFP+: 48/56 ports (total of 56 ports with breakout cable on port 50 and 52)
25GbE SFP: 48/56 ports (total of 56 ports with breakout cable on port 50 and 52)
40GbE QSFP+: 8 ports (QSFP+ port 50 and 52 can be configured as 4 x 10GbE interface or 40 Gbps port)
100GbE QSFP28: 8 ports (QSFP28 port 50 and 52 can be configured as 4 x 25GbE interface or 100 Gbps port)

Supported Transceivers and Cables

SFP GbE optical modules
SFP+ 10GbE optical modules
SFP+ DAC cables: 1/3/5 m twinax copper and 1/3/5/7 m active twinax copper
SFP28 DAC cables: 1/3 m twinax copper
SFP28 optics: Short reach (SR), long reach (LR)
QSFP+ to SFP+: 10GbE direct attach breakout copper (1/3 m twinax copper cable)

Common Features Across All Models

1 USB 2.0 port
1 RS-232 console port
Supported transceiver and direct attach cable compatibility
QSFP+ DAC cables: 1/3 m twinax copper
QSFP+ optics: SR4, LX4, ESR4, ER4, LR4
QSFP28 optics: SR4, ER4, PSM4, CWDM4, LR4
Rack installation kit included
Versatile four post mounting options for 19-in server rack or datacom rack
