products details

Home Products

ISR4331-SEC/K9 Integrated Services VPN Router with 2 External Antennas and 1 x10/100/1000Mbps WAN Ports Supporting Wi-Fi 802.11ac

Name: ISR4331-SEC/K9 Integrated Services VPN Router with 2 External Antennas and 1 x10/100/1000Mbps WAN Ports Supporting Wi-Fi 802.11ac
Brand: Beijing Hui Tong High Tech Limited.
SKU: ISR4331-SEC/K9
Price: 2,244.00 USD
Availability: InStock

Model Number:	ISR4331-SEC/K9
MOQ:	1
Price:	$2219-$2269
Payment Terms:	T/T,D/P,D/A

Detail Information

Product Description

Detail Information

Place of Origin:

China

With Modem Function:

Yes

Standards And Protocols:

Wi-Fi 802.11ac, Wi-Fi 802.11n, Wi-Fi 802.11b, Wi-Fi 802.11g

Wi-fi Supported Frequency:

2.4G & 5G

Supports Wds:

Yes

Supports Wps:

Yes

Wi-fi Transmission Standard:

802.11b

Wired Transfer Rate:

10/100/1000Mbps

2.4g Wi-fi Transmission Rate:

1200 Mbps

Encryption Type:

WPA2

Private Mold:

Yes

Products Status:

New

Type:

With 5G Sim Card

Application:

Function:

SDK Available

Lan Ports:

Antennas:

2 External Antennas

Wan Ports:

1 X10/100/1000Mbps

Brand Name:

Place Of Origin:

Shanghai, China

5g Wi-fi Transmission Rate:

1000Mbps

Size:

Customized Size

Color:

Customizable

Suitable For:

Workstation, Laptop, Desktop

Highlight:

ISR4331-SEC/K9 multi-service VPN router

Gigabit router with external antennas

VPN router with WAN ports

Product Description

ISR4331-SEC/K9 Integrated Multi-service VPN Gigabit Router with 2 External Antennas

High-performance multi-service VPN gigabit router featuring 1 x 10/100/1000Mbps WAN ports and comprehensive security capabilities.

Product Configuration

Type	ISR4331/K9 with Security Bundle

Performance Specifications

Aggregate Throughput	100 Mbps to 300 Mbps

Port Configuration

Total onboard WAN or LAN 10/100/1000 ports	3
RJ-45-based ports	2
SFP-based ports	2

Expansion & Module Slots

Enhanced service-module slots	1
Doublewide service-module slots	0
NIM slots	2
OIR (all I/O modules)	Yes
Onboard ISC slot	1

Memory Specifications

Default memory DDR3 ECC DRAM (Combined control/services/data planes)	4 GB
Maximum memory DDR3 ECC DRAM (Combined control/services/data planes)	16 GB
Default memory DDR3 ECC DRAM (data plane)	N/A
Maximum memory DDR3 ECC DRAM (data plane)	N/A
Default memory DDR3 ECC DRAM (control/services plane)	N/A
Maximum memory DDR3 ECC DRAM (control/services plane)	N/A
Default flash memory	4 GB
Maximum flash memory	16 GB

Connectivity & Ports

External USB 2.0 slots (type A)	1
USB console port - type B mini (up to 115.2 kbps)	1
Serial console port - RJ45 (up to 115.2 kbps)	1
Serial auxiliary port - RJ45 (up to 115.2 kbps)	1

Power Specifications

Power-supply options	Internal: AC and PoE
Redundant power supply	N/A
AC input voltage	100 to 240 VAC autoranging
AC input frequency	47 to 63 Hz
AC input current range, AC power supply (maximum)	3 to 1.3A
AC input surge current	60 A peak and less than 5 Arms per half cycle
Typical power (no modules) (watts)	42
Maximum power with AC power supply (watts)	250
Maximum power with PoE power supply (platform only) (watts)	530
Maximum endpoint PoE power available from PoE power supply (watts)	250
