products details

Created with Pixso. Home Created with Pixso. Products Created with Pixso.
Motherboards
Created with Pixso.

Customized ROG STRIX X570-E GAMING WIFI II Motherboard

Customized ROG STRIX X570-E GAMING WIFI II Motherboard

Customized ROG STRIX X570-E GAMING WIFI II Motherboard

MOQ: 2 pieces
Price: CN¥2,145.45/pieces >=2 pieces
Detail Information
Product Description
Detail Information
Item Condition:
New
Package:
Yes
Ports:
SATA, PCI-Express X16, USB 2.0, PS2, USB 3.0, HDMI
With Cpu:
No
Memory Bank:
2 DDR4 DIMM
Cpu Type:
Intel
Chipset:
Other
Maximum Ram Capacity:
16GB
Memory Channel:
Double
Private Mold:
NO
Products Status:
New
Application:
Server/Workstation
Chipset Manufacturer:
/
Socket Type:
LGA 1151
Form Factor:
/
Memory Type:
Other
Graphics Card Type:
/
Hard Drive Interface:
SATA
Brand Name:
/
Place Of Origin:
Shanghai, China
Product Name:
Motherboards
Size:
Customized Size
Color:
Customizable
Product Description
Product Description
Customized ROG STRIX X570-E GAMING WIFI II Motherboard 0
Customized ROG STRIX X570-E GAMING WIFI II Motherboard 1
Customized ROG STRIX X570-E GAMING WIFI II Motherboard 2
Customized ROG STRIX X570-E GAMING WIFI II Motherboard 3
Customized ROG STRIX X570-E GAMING WIFI II Motherboard 4
Customized ROG STRIX X570-E GAMING WIFI II Motherboard 5
Customized ROG STRIX X570-E GAMING WIFI II Motherboard 6
Specification
CPU
AMD Ryzen™ 5000 Series/ 5000 G-Series/ 4000 G-Series/ 3000 Series/ 3000 G-Series/ 2000 Series/ 2000 G-Series Desktop Processors
Chipset
X570
Memory
AMD Ryzen™ 5000 Series/ 3000 Series Desktop Processors
4 x DIMM, Max. 128GB, DDR4
4600(O.C.)/4400(O.C.)/4266(O.C.)/4133(O.C.)/4000(O.C.)/3866(O.C.)/3733(O.C.)/3600(O.C.)/3466(O.C.)/3400(O.C.)/3200/3000/2933/2800/2666/2400/2133,
un-buffered memory
AMD Ryzen™ 5000 and 4000 G-Series Processors
4 x DIMM, Max. 128GB, DDR4
5100(O.C)/4800(O.C.)/4600(O.C)/4466(O.C.)/4400(O.C)/4266(O.C.)/4133(O.C.)/4000(O.C.)/3866(O.C.)/3600(O.C.)/3466(O.C.)/3200/3000/2800/2666/2400/2133,
un-buffered memory
AMD Ryzen™ 2000 Series Desktop Processors
4 x DIMM, max. 128GB, DDR4 3600(O.C.)/3466(O.C.)/3400(O.C.)/3200(O.C.)/3000(O.C.)/2933/2800/2666/2400/2133, un-buffered memory
AMD Ryzen™ 2000 and 3000 G-Series Desktop Processors
4 x DIMM, max. 128GB, DDR43200(O.C.)/3000(O.C.)/2933/2800/2666/2400/2133, un-buffered memory
Dual Channel Memory Architecture
ECC Memory (ECC mode) support varies by CPU.
Graphics
1 x HDMI 2.0
1 x DisplayPort
1 x HDMI® port
- Supports HDMI 2.0b with maximum resolution of 4096 x 2160 @ 60 Hz
- Supports DisplayPort 1.2 with max. resolution 4096 x 2160 @ 60 Hz
* VGA resolution support depends on processors' or graphic cards' resolution. For more details about the video input and output
settings please refer to the user manual.
Wireless & Bluetooth
Wi-Fi 6E
2x2 Wi-Fi 6E (802.11 a/b/g/n/ac/ax)
Supports 2.4/5/6GHz frequency band*
Bluetooth v5.2
Form Factor
ATX
LED Lighting
RGB
Dimensions (W x L)
12.0" x 9.6"
Power Pin
1 x 24-pin Main Power connector
1 x 8-pin +12V Power connector
1 x 4-pin +12V Power connector
Product Description
Company Profile
Customized ROG STRIX X570-E GAMING WIFI II Motherboard 7
Customized ROG STRIX X570-E GAMING WIFI II Motherboard 8
Customized ROG STRIX X570-E GAMING WIFI II Motherboard 9
Packing & Delivery
Customized ROG STRIX X570-E GAMING WIFI II Motherboard 10
FAQ
Customized ROG STRIX X570-E GAMING WIFI II Motherboard 11
