CS-KIT-K9 Offers Videodelivers the unmatched video and audio experience customers have come to expect

MOQ:	2 pieces
Price:	CN¥26,981.72/pieces 2-49 pieces

Detail Information

Product Description

Detail Information

Place Of Origin:

Shanghai, China

Brand Name:

Type:

Video Conference System, Network Conference System, Audio Conference System

Function:

Voting

Private Mold:

Yes

Product Name:

Conference Cameras

MOQ:

1PCS

Warranty:

1year

Camera:

Webcam

Package:

Original Packaging

Product Description

Specification

Product Description

Optional hardware components	● Cisco Table Microphone ● Microphone extension cable ● HDMI second monitor cable 1.5 m/4.9 ft. ● HDMI presentation cable 8 m/26.2 ft.
Bandwidth	● Up to 6 Mbps point-to-point
Minimum bandwidth for resolution / frame rate	● H.264: ● 720p30 from 768 kbps ● 720p60 from 1152 kbps ● 1080p30 from 1472 kbps ● 1080p60 from 2560 kbps
Firewall traversal	● Cisco Expressway technology ● H.460.18, H.460.19 firewall traversal
Video standards	● H.264, H.265
Video inputs	● One HDMI input supports formats up to maximum 4K (3840 x 2160) at 30 fps including HD1080p60 ● Consumer Electronics Control (CEC) 2.0
Video outputs	● Two HDMI outputs support formats up to 3840 x 2160p60 (4Kp60) ● Live video resolutions (encode and decode) up to 1920 x 1080p30 and p60 (HD1080p) ● Consumer Electronics Control (CEC) 2.0
Audio standards	● G.711, G.722, G.722.1, G.729, AAC-LD, and Opus
Audio features	● High-quality 20 kHz audio ● Prepared for subwoofer (line out) ● Prepared for inductive loop (line out) ● Automatic Gain Control (AGC) ● Automatic noise reduction ● Active lip synchronization
Audio inputs	● Two microphones, 4-pin mini-jack ● One audio in from HDMI ● Internal microphone ● Bluetooth - Not available on Non Radio Version
Audio outputs (external)	● 1 line out mini-jack (stereo) ● Bluetooth - Not available on Non Radio Version
Speakers (integrated)	● High-quality speakers: five speakers in balanced configuration ● Frequency response 70 Hz to 20 kHz ● Amplifier power: 24W ● Max output level SPL 86 dB
Other interfaces	● USB 2.0 port, micro USB port, factory reset pinhole
Power	● 100 to 240 VAC, 50/60 Hz, 12V DC input ● Average 20W, peak 70W
Operating temperature and humidity	● 0°C to 40°C (32°F to 104°F) ambient temperature ● 10% to 90% Relative Humidity (RH)
