USG6525E-AC Enterprise Network Firewall with 1 Gbps Throughput, 1U Rack Mountable Design, and VPN Support

Name: USG6525E-AC Enterprise Network Firewall with 1 Gbps Throughput, 1U Rack Mountable Design, and VPN Support
Brand: Beijing Hui Tong High Tech Limited.
SKU: USG6525E-AC
Price: 865.00 USD
Availability: InStock

Model Number:	USG6525E-AC
MOQ:	1
Price:	$850-$880
Payment Terms:	T/T,D/P,D/A

Detail Information

Product Description

Detail Information

Place of Origin:

China

Products Status:

Stock

Type:

Wireless

Vpn Support:

Yes

Throughput:

1 Gbps

Model Number:

USG6525E-AC

Place Of Origin:

China

Condition:

Original

Warranty:

1 Year

MOQ:

Highlight:

HW USG6525E Enterprise Class Firewalls

USG6525E-AC Network Firewall

USG6525E Enterprise Class Firewalls

Product Description

HW USG6525E Series Enterprise Class Firewalls

Product Overview

The USG6525E-AC is an enterprise-class network firewall designed for robust security and high-performance network protection in business environments.

Basic Specifications

Part Number	02353AFX
Model	USG6525E-AC
Description	USG6525E AC Host (2GE WAN+8GE Combo+2*10GE SFP+, 1 AC power)
First Supported Version	V600R007C00

Physical Specifications

Installation Type	Rack Work bench
Cabinet Installation Standard	Cabinet with a depth of 600 mm or above
Dimensions without Packaging	43.6 mm x 442 mm x 420 mm (1.72 in. x 17.4 in. x 16.54 in.)
Dimensions with Packaging	220 mm x 550 mm x 530 mm (8.66 in. x 21.65 in. x 20.87 in.)
Chassis Height	1 U
Weight with Packaging	USG6525E-AC (02353AFX): 8.75 kg (19.29 lb) USG6525E-AC (02353AFX-001): 7.93 kg (17.48 lb) USG6525E-AC (02353AFX-002): 7.93 kg (17.48 lb)
Weight without Packaging	USG6525E-AC (02353AFX): 5.8 kg (12.79 lb) USG6525E-AC (02353AFX-001): 5.95 kg (13.12 lb) USG6525E-AC (02353AFX-002): 5.95 kg (13.12 lb)

Hardware Specifications

CPU	1 CPU, 4 cores/CPU, up to 1.4 GHz
Memory	DDR4 4 GB
NOR Flash	USG6525E-AC (02353AFX): 32 MB USG6525E-AC (02353AFX-001): 32 MB USG6525E-AC (02353AFX-002): 32 MB Note: The NOR flash memory size of devices delivered later is 64 MB. You can run the display version command to check the NOR flash memory size.
NAND Flash	2 GB
Hard Disk	Optional. M.2 SSD (64GB/240GB), hot-swappable.
Console Port	RJ45
Eth Management Port	RJ45

Power & Environmental Specifications

Maximum Power Consumption	USG6525E-AC (02353AFX): 40 W USG6525E-AC (02353AFX-001): 45.3 W USG6525E-AC (02353AFX-002): 45.3 W
Maximum Heat Dissipation	USG6525E-AC (02353AFX): 136.8 BTU/hour USG6525E-AC (02353AFX-001): 154.4 BTU/hour USG6525E-AC (02353AFX-002): 154.4 BTU/hour
MTBF	68.98 years
MTTR	2 hours
Power Supply Mode	AC built-in
Number of Power Modules	1
Rated Input Voltage	100 V to 240 V, 50 Hz/60 Hz
Input Voltage Range	90 V to 290 V, 47 Hz to 63 Hz
Types of Fans	Pluggable
Number of Fan Modules	1
Heat Dissipation Mode	The fan module locates at the air exhaust of the system.
Airflow Direction	Air inlet from front and air outlet from rear
Redundant Power Supply	Two power modules are supported for 1+1 power redundancy.
Long-term Operating Temperature	0°C to 45°C
Storage Temperature	-40°C to 70°C
Long-term Operating Relative Humidity	5% RH to 95% RH, non-condensing
Storage Relative Humidity	5% RH to 95% RH, non-condensing
Long-term Operating Altitude	0 m to 5000 m
Storage Altitude	0 m to 5000 m

Frequently Asked Questions

What are your advantages?

We are a professional supplier in network equipment field more than five years. We supply original brand products with good price to customers. We have professional sales team provide 24 hours free-consulting, and we also have professional technical team and after-sales department.

What's the warranty of your products?

One year (except for the used products).

What's the MOQ for your products?

1 piece.

What's the payment terms?

Pre T/T or PayPal or West Union or Alibaba Trade Assurance order.

What's the package?

Original packing. For the outside, we will pack it in an empty box to protect from damaged during transportation, and ensure you will receive the goods in good condition.
